BONFIGLIOLI VECTRON Frequency Inverter ACT 201-11FA

BONFIGLIOLI VECTRON Frequency Inverter ACT 201-11FA

General DescriptionThe Bonfiglioli Vectron ACT 201-11FA is a compact and efficient frequency inverter designed for controlling the speed of asynchronous three-phase electric motors. It is part of the ACT 200 series, known for its flexibility, reliability, and ease of integration in industrial automation systems. This model is suitable for a wide range of applications including conveyors, pumps, fans, and other machinery requiring variable speed control.

Electrical Specifications

• Input voltage: 3-phase, 400 V AC (±10%)

• Frequency: 50/60 Hz

• Output voltage: 3-phase, proportional to input voltage

• Output power: 1.1 kW

• Rated output current: Approx. 2.6 A

• Overload capacity: 150% for 60 seconds

• Switching frequency: Adjustable, typically from 2 kHz to 16 kHz

Control and Features

• Control type: V/f (voltage/frequency) and sensorless vector control

• Built-in PID controller

• Digital and analog inputs/outputs for flexible system integration

• Built-in control panel with LED indicators and basic programming keys

• Communication options: RS-485 (Modbus RTU)

Mechanical and Environmental

• Cooling: Integrated fan cooling system

• Protection class: IP20

• Operating temperature: -10°C to +50°C

• Storage temperature: -25°C to +70°C

• Humidity: Up to 95% non-condensing

• Mounting: Wall or panel mounting

Dimensions and Weight

• Approximate dimensions: 200 mm (H) x 100 mm (W) x 170 mm (D)

• Weight: Around 1.5 kg

ApplicationsThe ACT 201-11FA is ideal for applications in light to medium industrial processes where precise speed regulation, compact size, and energy efficiency are required. Typical use cases include packaging lines, small conveyors, machine tools, and HVAC systems.

SummaryBonfiglioli Vectron ACT 201-11FA offers a reliable and easy-to-use solution for speed control of AC motors. Its compact design, integrated control functions, and robust performance make it a valuable component for automation and motion control systems.

On this page you will find the user manual for BONFIGLIOLI VECTRON ACT 201-11FA. Get detailed technical specifications, installation and operating instructions to ensure optimum performance and reliability.

Manual for BONFIGLIOLI VECTRON ACT 201-11FA

https://cpupartnergroup.com/image/pdf/OperatingInstructions_ACT_VEC211R4.pdf
